SP45 Falcon

The SP45 Falcon is a USB 2.0, WiFi and Bluetooth control platform based on the highly capable, low-power Xilinx Spartan6 FPGA. Falcon has low profile connectors for easy integration of Nand Logic, or 3rd party, sensor arrays and module boards. This, combined with its wireless and USB interface capability, makes the Falcon easy to deploy into your current platform.

In combination with Nand Logic IP,  the Spartan FPGA gives developers the ability to construct and integrate hardware accelerators, soft core processors, DSP, AI networks, and much much more!


Nand Logic IP is specifically architected to give developers instant access to all of the peripherals and data path mediums available on our boards.  Dramatically decrease your development cycle by taking advantage of the IP we have to offer.

Our interfaces are intuitive and easy to embed into your current environment – we can provide any custom IP you need. Let us be a part of your development team and let us help you maximize the potential of the SP45 FALCON!

Prototyping and OEM Integration

Nand Logic FPGA control modules are designed to be the ideal turnkey solution for prototype and OEM product integration.


FTDI’s USB IC with processor FIFO interface provides performance at over 480Mb/s real world data transfers. It has the capability of being configured in a variety of industry standard serial or parallel interfaces.  This FTDI USB has two multi-protocol synchronous serial engines (MPSSEs) that allow for communication using JTAG, I2C and SPI on two channels simultaneously.

1-GiB DDR3

Integrated 1-GiByte DDR3 provides loads of high-speed on-board memory for high-performance applications, including image and audio processing.


Integrated 16 MiBytes of on-board serial Flash for standalone FPGA booting and SoC system nonvolatile storage with a separate 16 MiByte serial Flash for exclusive image FPGA use.

Wi-Fi Module

IEEE 802.11b/g/n compliant – runs the full Wi-Fi and TCP/IP networking stacks, completely offloading the host microcontroller.  Supports WPA/WPA2 security modes and TLS/SSL and HTTPs security protocols.


Optimized for transmitting high quality audio and data.  The Bluetooth module is a Certified Bluetooth 5 module with integrated antenna, and is ideal for easily adding high quality audio and data communication.

The module provides dual-mode Bluetooth Classic and Bluetooth Low Energy (BLE) for connecting consumer and industrial devices that require multiple connections and/or high-end audio applications.


  • Image & video capture / processing
  • Sensor data acquisition
  • ASIC / hardware-based simulation and verification
  • Bioinformatics (DNA search and pattern matching)
  • Digital communications
  • High-speed USB / FPGA co-processor
  • Evaluation platform for your product prototypes
  • Custom test equipment
  • Cryptography
  • Data Security

Specific Deployments

  • CMOS sensor array test platform
  • Radar system development
    • Test interface
    • System integration
    • Field testing
  • Evaluation platform for ASICs
  • UAV control platform
  • Camera interface for IR and LIDAR 3D cameras
  • AI/ML model deployment
  • University research, classroom design projects

Features & Specifications

Base Station

Main unit that houses the electronics:

  • Infinity Sensor Array
  • AEGIS extra sensory perception suite
